PA PTFE ALLOY
PA PTFE ALLOY
Download the file to view the specific parameters
product details
Engineered to Slide — The Self-Lubricating Alloy That Outperforms Metal Bushings
Material Overview
PA/PTFE is one of the most specialized polymer alloys in the engineering plastics universe. By dispersing polytetrafluoroethylene microparticles uniformly throughout a polyamide matrix, this alloy achieves a friction coefficient and wear rate approaching lubricated metal bearings — without ever needing external lubrication.
For maintenance-free dynamic equipment, food-contact-clean machinery, and chemical-resistant moving parts, PA/PTFE replaces components that traditionally required bronze or oil-impregnated metal solutions. Renhong’s compounding technology ensures uniform PTFE dispersion at the micron scale — the difference between a bushing surviving 1,000 hours of dynamic service and one lasting 50,000.
Key Features
⚙️ Low Friction Coefficient
Dynamic friction coefficient as low as 0.10–0.15 against steel — comparable to lubricated bearings.
🛡️ Strong Wear Resistance
Wear factor (K) reduced by 80–90% compared to unfilled nylon, extending part life in dynamic applications.
🧪 Excellent Chemical Resistance
PTFE phase provides resistance to aggressive chemicals, fuels, and process fluids that attack pure nylon.
🔥 Wide Service Temperature
Continuous use temperature up to 100°C, with PTFE-stabilized performance from –40°C upward.
💧 Self-Lubricating in Service
No external lubrication required — suitable for maintenance-free equipment and food-contact-clean designs.
Typical Applications
Mechanical Engineering
- Bearings, bushings, and sliding elements
- Precision gears and timing components
- Conveyor system rollers and maintenance-free pivot points
Chemical Industry
- Chemical-resistant pipe adapters and fittings
- Pump impellers and process valve components
- Chemical handling equipment internals
Food & Pharmaceutical Machinery
- Food-grade processing equipment sliding parts
- Medical device gears and quiet-running mechanisms
- Pharmaceutical machinery components
Why Choose Renhong
✓ Engineered PTFE micron-scale dispersion for consistent tribological performance
✓ Wear factor verified through ASTM D3702 testing protocols
✓ Food-contact-compliant grade for hygiene-critical machinery
✓ Glass-fiber-reinforced structural variant for load-bearing sliding parts
✓ Chemical compatibility documentation supports process industry qualification
The information provided on this page reflects typical performance characteristics of Renhong’s polymer alloy products under standard testing conditions. Actual material behavior in finished parts may vary depending on processing parameters, part geometry, additive packages, and end-use environments. Customers are encouraged to validate material suitability through application-specific testing and to consult Renhong’s technical team for grade selection, regulatory compliance documentation, or production-ready data sheets. All trademarks and product names referenced are the property of their respective owners.
